Product Description
Description
- Eight different Hub Arrangements available
- Tapered threaded hubs to provide ground continuity
- Smooth integral hub bushing to protect conductor insulation when pulling
- Threaded cover openings
- Surface covers furnished with boxes
- Neoprene O-Ring gasket and ground screw standard Light Weight corrosion resistant copper-free aluminum Attractive sandblast finish
- Atex certification (optional)
Prose
Available Sizes
The AXC Series are available in a number of different sizes to fit all types of hazardous locations. Please see the Product Catalogue for available sizes and detailed specifications.
ATEX Certification (Optional)
ATEX certification is available upon request. Certain features are added to the AXJ Series if ATEX is required:
- External ground screw
- Cover with set screw
Standards
- Approvals
UL & cUL -File No. 94590
ATEX -File No. 97D.122602U, ExdIIc, IP66
- Compliances
Class I, Div. 1 & 2, Groups A, B, C & D
Class II, Div 1 & 2, Groups E, F & G Class III
NEMA 4, 7 & 9
For detailed specifications, refer to the Product Catalogue.
