Product Description
Description
- All Enclosures are available with NEMA 4 O-Ring Suitable for surface mounting
- Light weight corrosion-resistant copper-free aluminum Attractive wheelabrate finish
- Durable Mounting Feet and easily accessible ground screw
- ABB & Sprecher +Schuh Starters (Optional) (with C8 -Custom Circuit Breaker Handle)
- Mini Push Button Manual Motor Starters available with Cutler Hammer starter
- Available to use with Mini Pilot Device Series (1 center to center)
Prose
Available Sizes
The XRTC/XRMC Series are available in a number of different sizes to fit all types of hazardous locations. Please see the Product Catalogue for available sizes and detailed specifications.
Materials
- Enclosure
Copper-free Aluminum (less than 0.25% copper)
- Cover Bolts
Cad-Plated or Stainless Steel (Please Specify)
- Mounting Pan (Optional)
Aluminum, Galvanized Steel, or Phenolic Materials (Please Specify)
- Din-Rail
Aluminum
For detailed specifications, refer to the Product Catalogue.
Standards
- Approvals
UL CLASSIFIED - Standard 886 - E94590
cUL (CXI 4 Series) - Standard C22.2 No. 30-M1986 and No. 25-1966
CSA Certified (CXI 3 Series) - Standard C22.2 No. LR64264
- Compliances
N.E.C. - Class. I, Div. 1 & 2 Groups B*, C & D
Class. II, Div. 1 & 2 Groups E, F & G
Class. III
NEMA 7 & 9 (Optional 3, 4X)
For detailed specifications, refer to the Product Catalogue.
